UL94 V-0 Fire Retardant Silicone Foam ROHS 2.0 Environmental Standards 0.1 W/ Mk Thermal Conductivity

Brand Name:	Ohory Electric

Detail Information

Product Description

Detail Information

Certification:

ISO 9001/UL/IEC/CNAS/CMA

Proportion:

0.45+0.03

Flame Retardant:

UL94 V-0

Environmental Standards:

ROHS 2.0

Volume Resistivity:

≥1.0x1015 Q-cm

Width:

<910mm

Temperature Resistance:

-60°C To 300°C

Tensile Strength:

≥300KPa

Thermal Conductivity:

<0.1 W/(mk)

Highlight:

ROHS 2.0 Silicon Foam

Cushioning fire retardant silicone foam

Product Description

UL94 V-0 Flame Retardant Silicon Foam with ROHS 2.0 Environmental Standards and 0.1 W/mk Thermal Conductivity

Key Specifications

Attribute	Value
Proportion	0.45+0.03
Flame Retardant	UL94 V-0
Environmental Standards	ROHS 2.0
Volume Resistivity	≥1.0×10¹⁵ Ω·cm
Width	<910mm
Temperature Resistance	-60°C to 300°C
Tensile Strength	≥300KPa
Thermal Conductivity	<0.1 W/(m·K)

Product Overview

Ceramic silicone foam is an innovative material combining advanced material science with premium-grade silicone rubber. Through specialized formulation and production methods, this material transforms into a rigid ceramic-like substance when exposed to heat, offering exceptional fireproof and heat-insulating properties.

This unique material maintains the flexibility of conventional foam while demonstrating ceramic-like high-temperature resistance and strength under specific conditions, representing a significant advancement in material technology.

Key Features

Flame Retardant: UL94 V-0 certified for high fire resistance
Thermal Insulation: Low thermal conductivity (<0.1 W/m·K) ensures stable performance
Flexible & Resilient: Soft texture with excellent elasticity for optimal fit
Chemical Resistance: Withstands corrosion from various substances
Environmentally Safe: Manufactured with eco-friendly materials and multiple international certifications

Technical Parameters

Feature	Specification
Primary Functions	Insulation, Sealing, Cushioning, Shock Absorption
Thickness Range	0.5-30 mm
Water Absorption	<5.0%

Applications

Construction: Fire blocking, sealing, heat and thermal insulation for building safety

Electronics: Protection and fire prevention for electronic products and equipment

Rail Transit: Vehicle interior fire prevention, heat insulation, and noise reduction

New Energy Vehicles: Battery pack protection, fire prevention, and sound insulation

Frequently Asked Questions

What is the brand name of the Silicon Foam product?

Ohory Electric

Where is the Silicon Foam product manufactured?

Dongguan, China

What certifications does the Silicon Foam product have?

ISO 9001, UL, IEC, CNAS, and CMA certifications

Is the Silicon Foam product suitable for electrical applications?

Yes, it is specifically designed for electrical applications

Can the Silicon Foam product withstand high temperatures?

Yes, it maintains performance from -60°C to 300°C
