High Temperature Resistance Aerogel Mat For Aerospace Defense Heat Resistant Temperature 350°C-1300°C

Brand Name:	Ohory Electric
MOQ:	1000 Pcs
Price:	Confirm Price Based On Product
Packaging Details:	According To Requirement
Payment Terms:	TT/LC

Detail Information

Product Description

Detail Information

Certification:

ISO 9001/UL/IEC/CNAS/CMA

Application Scenarios:

Aerospace And Defense, High Themal Insulation Protection For Power Battery Cells And Modules In Advanced New Energy Passenger Vehicles

Insulation Resistance:

>500MΩ(1000V，DC，60s)

Heat Resistant Temperature:

350°C-1300°C

Thermal Conductivity:

25°C，≤0.025W/(m·K)/500°c，≤0.08W/(m·K)

Color:

White/Black

Hydrophobicity:

>98%

Fire Rating:

UL94 V-0

Voltage Resistance:

No Breakdown,arcing,leakage Current

Highlight:

Aerospace Aerogel mat

High Temperature Resistance Aerogel Mat

Product Description

High Temperature Resistance Aerogel Mat

Aerospace and Defense Grade Thermal Insulation (350°C-1300°C)

Key Features

Exceptional heat resistance from 350°C to 1300°C
Ultra-low thermal conductivity: ≤0.025W/(m·K) at 25°C
UL94 V-0 fire rating for superior safety
High hydrophobicity (>98%) for moisture resistance
Available in white or black color options
Customizable thickness from 0.5mm to 6mm

Technical Specifications

Attribute	Value
Application Scenarios	Aerospace & Defense, Power Battery Insulation for New Energy Vehicles
Insulation Resistance	>500MΩ (1000V, DC, 60s)
Heat Resistant Temperature	350°C-1300°C
Thermal Conductivity	25°C: ≤0.025W/(m·K)/500°C: ≤0.08W/(m·K)
Voltage Resistance	No breakdown, arcing, leakage current <1mA (3000V, DC, 60s)
Hydrophobicity	>98%
Fire Rating	UL94 V-0

Product Description

Ohory Electric's Aerogel Blanket represents a breakthrough in thermal insulation technology, combining cutting-edge materials with superior performance characteristics. This advanced insulation solution delivers unparalleled thermal protection for demanding aerospace, defense, and new energy vehicle applications.

Available in both white and black variants, the aerogel blanket offers exceptional fire resistance (UL94 V-0) and maintains its insulating properties even in high-humidity environments thanks to its >98% hydrophobicity. The customizable thickness range from 0.5mm to 6mm allows for precise adaptation to specific thermal management requirements.

Certifications & Manufacturing

Manufactured in Dongguan, China, our aerogel blankets meet rigorous quality standards including ISO 9001, UL, IEC, CNAS, and CMA certifications. This ensures consistent performance and reliability for critical applications.

Ordering Information

Minimum Order Quantity: 1000 pieces
Packaging: Customizable to customer requirements
Payment Terms: TT or LC
Delivery: Timeframe based on order quantity

Frequently Asked Questions

What is the brand name of the Aerogel Blanket product?

The brand name is Ohory Electric.

Where is the Aerogel Blanket manufactured?

Our manufacturing facility is located in Dongguan, China.

What certifications does the product have?

Certifications include ISO 9001, UL, IEC, CNAS, and CMA.

What is the minimum order quantity?

The minimum order quantity is 1000 pieces.

Can packaging be customized?

Yes, packaging details are handled according to customer requirements.
