Plug-In Busway System with Tool-Free Tap-Off Units for 400A-1250A AI Server Rack Power Distribution

Brand Name:	ohory
Model Number:	OH-PB-1250A
MOQ:	188 Meters
Price:	Negotiable
Packaging Details:	Wooden Box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO 9001/UL/IEC/CNAS/CMA

Rated Current:

400A - 1,250A

Rated Voltage:

AC 690V

Dielectric Withstand:

3,750V AC / 1 Min

Short-Circuit Withstand:

50kA / 1s

Insulation Class:

Class B (130°C)

Protection Grade:

Conductor Material:

High-conductivity Copper Busbars

Tap-Off Spacing:

Every 500 Mm, Tool-free Plug-in

Temperature Rise:

≤ 70K At Rated Current

Application:

AI Computing Power Centers, AI Data Centers, GPU Clusters, High-density AI Racks

Supply Ability:

1500 Meters Per Day

Highlight:

Tool-Free Tap-Off Plug-In Busway

400A-1250A AI Rack Busway

Rapid Deployment AI Power Busway

Product Description

Plug-In Busway 400A-1250A Tool-Free Tap-Off Units For AI Server Rack Power Distribution

Product Overview

This plug-in busway system is engineered for flexible power distribution to AI server racks. Rated from 400A to 1,250A, it combines compact plug-in boxes with tool-free installation, allowing data center operators to add or relocate rack power points in minutes as AI workloads evolve.

Core Advantages

Tool-Free Tap-Off Units: Plug-in tap-off boxes install without special tools every 500 mm, cutting commissioning time for AI rack rows.
Online Expansion: New tap-off units can be added while the busway remains energized, supporting zero-downtime AI capacity growth.
Flexible Rack Powering: Each tap-off delivers stable single or three phase power to AI server racks and in-row PDUs.
Compact Plug-In Design: Lightweight enclosure simplifies overhead mounting above AI server rows and saves valuable floor space.

Technical Specifications

Parameter	Value
Rated Current	400A - 1,250A
Rated Voltage	AC 690V
Dielectric Withstand	3,750V AC / 1 min
Short-Circuit Withstand	50kA / 1s
Insulation Class	Class B (130°C)
Protection Grade	IP54
Conductor Material	High-conductivity copper busbars
Tap-Off Spacing	Every 500 mm, tool-free plug-in
Temperature Rise	≤ 70K at rated current

Applications

AI computing power centers and AI data centers
GPU cluster rooms and high-density AI server racks
UPS output to AI rack power distribution units (PDU)
Colocation and enterprise data halls with high-density AI workloads

Quality & Service

Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. OEM and ODM support available, with complete drawings and technical documentation provided upon request.
