Lightweight Aluminum Conductor Busway 400A-4000A for AI Colocation Data Centers

Brand Name:	ohory
Model Number:	OH-ACB-4000A
MOQ:	188 Meters
Price:	Negotiable
Packaging Details:	Wooden Box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO 9001/UL/IEC/CNAS/CMA

Rated Current:

400A - 4,000A

Rated Voltage:

AC 690V

Dielectric Withstand:

3,750V AC / 1 Min

Short-Circuit Withstand:

65kA / 1s

Insulation Class:

Class B (130°C)

Protection Grade:

Conductor Material:

High-grade Aluminum Alloy, Tin Plated Joints

Temperature Rise:

≤ 70K At Rated Current

Weight Advantage:

Approx. 40% Lighter Than Equivalent Copper Busway

Application:

AI Computing Power Centers, AI Data Centers, GPU Clusters, High-density AI Racks

Supply Ability:

1500 Meters Per Day

Highlight:

Aluminum Conductor Lightweight Busway

Economical AI Colocation Busway

400A-4000A Aluminum Busway

Product Description

Aluminum Conductor Busway 400A-4000A Lightweight Design For AI Colocation Data Centers

This aluminum conductor busway system is the cost-efficient choice for AI colocation data centers. Rated 400A to 4,000A, its lightweight aluminum conductors reduce structural loading and simplify installation, while precision alloy processing keeps joints stable and power delivery reliable.

Core Advantages

Lightweight Structure: Aluminum conductors cut total busway weight, reducing ceiling and support structure requirements
Economical Solution: Lower material cost makes large-scale AI colocation rollouts more budget efficient
Easy Installation: Lighter sections enable faster rigging and shorter commissioning time on site
Reliable Joint Design: Tin plated and torque controlled connections maintain low resistance over the long term

Technical Specifications

Parameter	Value
Rated Current	400A - 4,000A
Rated Voltage	AC 690V
Dielectric Withstand	3,750V AC / 1 min
Short-Circuit Withstand	65kA / 1s
Insulation Class	Class B (130°C)
Protection Grade	IP54
Conductor Material	High-grade aluminum alloy, tin plated joints
Temperature Rise	≤ 70K at rated current
Weight Advantage	Approx. 40% lighter than equivalent copper busway

Applications

AI computing power centers and AI data centers
GPU cluster rooms and high-density AI server racks
UPS output to AI rack power distribution units (PDU)
Colocation and enterprise data halls with high-density AI workloads

Quality & Service: Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. OEM and ODM support available, with complete drawings and technical documentation provided upon request.
