IP68 Waterproof 630A-2500A Corrosion Resistant Busway System for AI Edge Data Centers

Brand Name:	ohory
Model Number:	OH-IPB-2500A
MOQ:	188 Meters
Price:	Negotiable
Packaging Details:	Wooden Box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO 9001/UL/IEC/CNAS/CMA

Rated Current:

630A - 2,500A

Rated Voltage:

AC 690V

Dielectric Withstand:

3,750V AC / 1 Min

Short-Circuit Withstand:

50kA / 1s

Insulation Class:

Class B (130°C)

Protection Grade:

IP68 (NEMA 6P Equivalent)

Conductor Material:

High-conductivity Copper Or Aluminum (optional)

Enclosure Treatment:

Corrosion Resistant, UV Stabilized

Temperature Rise:

≤ 70K At Rated Current

Application:

AI Computing Power Centers, AI Data Centers, GPU Clusters, High-density AI Racks

Supply Ability:

1500 Meters Per Day

Highlight:

IP68 Waterproof Busway System

AI Edge Data Center Power Busway

Outdoor Sealed Busway Enclosure

Product Description

IP68 Waterproof Busway System 630A-2500A Sealed Enclosure For AI Edge Data Center Power Supply

This IP68 waterproof busway system is purpose-built for AI edge data centers, containerized data centers and outdoor power supply points. Rated 630A to 2,500A, its fully sealed enclosure prevents ingress of water and dust, ensuring dependable power delivery in harsh environments.

Core Advantages

IP68 Fully Sealed: Complete protection against water immersion and dust ingress for outdoor and edge deployments
Corrosion Resistant Enclosure: Marine grade treatment withstands humidity, salt spray and temperature swings
Edge Data Center Ready: Ideal for containerized AI edge nodes, prefabricated micro data centers and outdoor UPS yards
Reliable Sealed Joints: Pre-tested joint seals maintain IP protection after repeated assembly and reconfiguration

Technical Specifications

Parameter	Value
Rated Current	630A - 2,500A
Rated Voltage	AC 690V
Dielectric Withstand	3,750V AC / 1 min
Short-Circuit Withstand	50kA / 1s
Insulation Class	Class B (130°C)
Protection Grade	IP68 (NEMA 6P equivalent)
Conductor Material	High-conductivity copper or aluminum (optional)
Enclosure Treatment	Corrosion resistant, UV stabilized
Temperature Rise	≤ 70K at rated current

Applications

AI edge data centers and containerized micro data centers
Outdoor power supply points and prefabricated substations
GPU clusters in harsh or semi-outdoor environments
AI data center auxiliary outdoor power distribution

Quality & Service

Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. OEM and ODM support available, with complete drawings and technical documentation provided upon request.
