AI+ Intelligent Busway System 1250A-6300A with AI Proactive Warning and Closed-Loop O&M for AI Data Centers

Brand Name:	ohory
Model Number:	AI+IB-6300A-W
MOQ:	188 Meters
Price:	Negotiable
Packaging Details:	Wooden Box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO 9001/UL/IEC/CNAS/CMA

Rated Current:

1,250A - 6,300A

Rated Voltage:

AC 690V

Power-Frequency Withstand:

Partial Discharge:

≤ 5 PC

Temperature Rise:

≤ 30 K At Full Load

Protection Grade:

Operating Temperature:

-20°C To +60°C

Insulation Technology:

Molecular-Shield Solid Insulation

Intelligent Features:

AI Proactive Warning, Closed-loop O&M, Online Monitoring Platform

Application:

AI Data Centers, GPU Clusters, HPC, 100kW-class High-density Racks, UPS Output To Rack Rows

Supply Ability:

1500 Meters Per Day

Highlight:

AI Proactive Warning Busway System

Closed Loop Maintenance Intelligent Busway

6300A Intelligent Power Backbone

Product Description

AI+ Intelligent Busway System 1250A-6300A AI Proactive Warning Closed Loop Maintenance For AI Data Centers

Product Overview

The CESKO AI+ Intelligent Busway is a next-generation intelligent power distribution backbone built for AI data centers. Rated 1,250A to 6,300A, it integrates high-current transmission, flexible tap-off, intelligent sensing, AI trend warning and closed-loop O&M in one architecture, upgrading power distribution from delivering power to continuously assuring power.

Core Advantages

AI Proactive Warning: Combines temperature-rise rate, environmental baseline and load-health models to identify risk trends before failures disrupt AI operations
Closed-Loop O&M: Warning, recommendations, work orders, action and review are linked end to end for traceable, verifiable outcomes
High-Density Capacity: Supports 100kW-class racks and GPU clusters with continuous high current, low impedance and low voltage drop
Real-Time Visibility: Temperature, current, voltage, power and power quality remain continuously visible across the power chain

Technical Specifications

Parameter	Value
Rated Current	1,250A - 6,300A
Rated Voltage	AC 690V
Power-Frequency Withstand	8 kV
Partial Discharge	≤ 5 pC
Temperature Rise	≤ 30 K at full load
Protection Grade	IP68
Operating Temperature	-20°C to +60°C
Insulation Technology	Molecular-Shield solid insulation
Intelligent Features	AI proactive warning, closed-loop O&M, online monitoring platform

Applications

AI data centers and AI computing power centers
GPU clusters and HPC computing halls
100kW-class high-density server racks
UPS output to high-density rack row power distribution

Quality & Service

Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. Intelligent busway system delivered with monitoring platform access, installation guidance and technical documentation. OEM and ODM support available.
