AI+ Intelligent Busway System with Molecular-Shield Integral Molding, 8.2 MPa Bond Strength, and Partial Discharge ≤ 5 pC for AI Data Centers

Brand Name:	ohory
Model Number:	AI+IB-PD5
MOQ:	188 Meters
Price:	Negotiable
Packaging Details:	Wooden Box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO 9001/UL/IEC/CNAS/CMA

Partial Discharge:

≤ 5 PC

Power-Frequency Withstand:

8 KV (no Breakdown)

Bond Strength:

8.2 MPa (insulation To Conductor)

Rated Current:

1,250A - 6,300A

Rated Voltage:

AC 690V

Temperature Rise:

≤ 30 K At Full Load

Protection Grade:

Operating Temperature:

-20°C To +60°C

Insulation Technology:

Molecular-Shield Integral Molded Solid Insulation

Application:

AI Data Centers, GPU Clusters, HPC, 100kW-class High-density Racks, UPS Output To Rack Rows

Supply Ability:

1500 Meters Per Day

Highlight:

Low Partial Discharge 5pC Insulation

High Bond Strength Insulation Busway

Integral Molded Solid Insulation Busway

Product Description

AI+ Intelligent Busway System Low Partial Discharge 5pC Insulation High Bond Strength For AI Data Center Reliability

Product Overview

AI+ Intelligent Busway System with Molecular-Shield Low Partial Discharge Insulation

Insulation determines how safely an AI data center busway performs under decades of high load. This AI+ intelligent busway uses Molecular-Shield integral molded solid insulation, formed continuously and seamlessly on the conductor, achieving partial discharge below 5pC, 8kV power-frequency withstand and 8.2MPa insulation-to-conductor bond strength.

Core Advantages

Partial Discharge ≤ 5pC: Minimal discharge activity reduces long-term erosion of insulation under high voltage stress.
8.2 MPa Bond Strength: Stable insulation-to-conductor bonding reduces delamination and aging risk over the product lifetime.
Seamless Integral Molding: No wrapping joints, overlaps or edge seals means fewer localized weak points and moisture paths.
Consistent Batch Quality: Controlled molding thickness and coverage reduce dependence on manual wrapping technique.

Technical Specifications

Parameter	Value
Partial Discharge	≤ 5 pC
Power-Frequency Withstand	8 kV (no breakdown)
Bond Strength	8.2 MPa (insulation to conductor)
Rated Current	1,250A - 6,300A
Rated Voltage	AC 690V
Temperature Rise	≤ 30 K at full load
Protection Grade	IP68
Operating Temperature	-20°C to +60°C
Insulation Technology	Molecular-Shield integral molded solid insulation

Applications

AI data centers and AI computing power centers
GPU clusters and HPC computing halls
100kW-class high-density server racks
UPS output to high-density rack row power distribution

Quality & Service

Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. Intelligent busway system delivered with monitoring platform access, installation guidance and technical documentation. OEM and ODM support available.
