AI+ Intelligent Busway System with Rapid Tap-Off Configuration and Online Installation for Scalable Rack Deployment

Brand Name:	ohory
Model Number:	AI+IB-TAP
MOQ:	188 Meters
Price:	Negotiable
Packaging Details:	Wooden Box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO 9001/UL/IEC/CNAS/CMA

Tap-Off Mode:

Rapid Configuration, Online Installation

Rated Current:

1,250A - 6,300A

Rated Voltage:

AC 690V

Power-Frequency Withstand:

Partial Discharge:

≤ 5 PC

Temperature Rise:

≤ 30 K At Full Load

Protection Grade:

Operating Temperature:

-20°C To +60°C

Insulation Technology:

Molecular-Shield Solid Insulation

Application:

AI Data Centers, GPU Clusters, HPC, 100kW-class High-density Racks, UPS Output To Rack Rows

Supply Ability:

1500 Meters Per Day

Highlight:

Rapid Tap Off Configuration Busway

Power Points Follow Business Demand

AI Data Center Flexible Tap Off

Product Description

AI+ Intelligent Busway System Rapid Tap Off Configuration Power Points Follow Demand For AI Data Centers

CESKO AI+ Intelligent Busway System with Rapid Flexible Tap-Off Configuration

Product Overview

In AI data centers, rack power, location and deployment pace change constantly. This AI+ intelligent busway allows tap-off points to be rapidly configured along rack rows, so power points follow the business: add, move or upgrade rack power quickly and support future expansion without re-engineering the backbone.

Core Advantages

Rapid Tap-Off Configuration: Power points can be configured around rack location, load and deployment schedule.
Power Points Follow Business: Tap-off layout adapts as AI workloads, rack rows and construction phases change.
Online Tap-Off Installation: New tap-off boxes install while energized, supporting zero-interruption modification.
Scalable Rack Deployment: From a few racks to full GPU cluster halls, the same backbone grows with demand.

Technical Specifications

Parameter	Value
Tap-Off Mode	Rapid configuration, online installation
Rated Current	1,250A - 6,300A
Rated Voltage	AC 690V
Power-Frequency Withstand	8 kV
Partial Discharge	≤ 5 pC
Temperature Rise	≤ 30 K at full load
Protection Grade	IP68
Operating Temperature	-20°C to +60°C
Insulation Technology	Molecular-Shield solid insulation

Applications

AI data centers and AI computing power centers
GPU clusters and HPC computing halls
100kW-class high-density server racks
UPS output to high-density rack row power distribution

Quality & Service

Manufactured under ISO 9001 quality management with UL/IEC/CNAS/CMA certified testing. Intelligent busway system delivered with monitoring platform access, installation guidance and technical documentation. OEM and ODM support available.
