418kWh Energy Storage Cabinet with Aerosol Fire Suppression and IP54 IP55 Protection for High Voltage BESS

Brand Name:	Ohory
Model Number:	ES-BP-1-416-418000-C-Y
MOQ:	1 Unit
Price:	USD 48000-58000 / Unit
Packaging Details:	Export-grade wooden frame packing with moisture-proof barrier, suitable for sea freight and long-distance transport
Payment Terms:	T/T,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

Tianjin, China

Certification:

CE, IEC 62619, UN38.3, ISO 9001:2015

Cell Type:

LFP (LiFePO4)

Battery Module Rated Capacity:

52.25 KWh

System Configuration:

1P416S

Battery Rated Voltage:

1331.2 Vdc

Battery Voltage Range:

1164~1497 Vdc

System Rated Capacity:

418 KWh

Rated Charge/Discharge Current:

75 Adc

Rated Power:

100 KW (400 Vac) / 200 KW (690 Vac)

Rated Output Voltage:

400 Vac / 690 Vac (3P+PE)

Rated Grid Frequency:

50 Hz

Cooling Method:

Liquid Cooling

Fire Fighting System:

Aerosol

IP Rating:

Electrical Compartment IP54, Battery Compartment IP55

Operating Temperature:

-20~50 Deg C (derating Above 45 Deg C)

Relative Humidity:

<=95%, Non-condensing

Max Operating Altitude:

4000 M (derating Above 2000 M)

Communication Interface:

Communication Protocol:

Corrosion Protection Level:

Weight:

4040 +/- 20 Kg

Dimensions (W X H X D):

1650 X 2280 X 1350 Mm

Max Parallel Units Per Busbar:

Supply Ability:

50 Units per Month

Highlight:

Aerosol Fire Suppression BESS

IP54 IP55 Protected Battery Cabinet

High Voltage Fuse Breaker Protection

Product Description

Aerosol Fire Suppression 418kWh Energy Storage Cabinet IP54 IP55 LFP Battery High Voltage BESS

Product Overview

Safety is engineered into every layer of this 418 kWh energy storage cabinet: LFP cell chemistry, aerosol fire suppression, HV box fuses on the DC input, AC breakers on the grid side, and a two-compartment enclosure rated IP54 for electrical equipment and IP55 for the battery room.

Multi-level BMS protection continuously monitors cell voltage, current and temperature, and the system is designed for safe installation by qualified technicians in compliance with international storage safety practice.

Key Features

Aerosol fire suppression system for the battery compartment
Electrical compartment IP54 and battery compartment IP55 protection
HV box fuse protection on DC input and breaker protection on AC input
LFP chemistry with intrinsic thermal stability
Multi-level smart BMS electrical, thermal and communication protection
C4 corrosion protection enclosure for outdoor installation

Technical Specifications

Cell Type	LFP (LiFePO4)
Battery Module Rated Capacity	52.25 kWh
System Configuration	1P416S
Battery Rated Voltage	1331.2 Vdc
Battery Voltage Range	1164~1497 Vdc
System Rated Capacity	418 kWh
Rated Charge/Discharge Current	75 Adc
Rated Power	100 kW (400 Vac) / 200 kW (690 Vac)
Rated Output Voltage	400 Vac / 690 Vac (3P+PE)
Rated Grid Frequency	50 Hz
Connection Method	AC bottom feed; auxiliary power 220 Vac L+N
Cooling Method	Liquid Cooling
Fire Fighting System	Aerosol
IP Rating	Electrical compartment IP54, battery compartment IP55
Operating Temperature	-20~50 °C (derating above 45 °C)
Relative Humidity	≤95%, non-condensing
Max Operating Altitude	4000 m (derating required above 2000 m)
Communication Interface	LAN
Communication Protocol	MQTT
Corrosion Protection Level	C4
Weight	4040 ± 20 kg
Dimensions (W x H x D)	1650 x 2280 x 1350 mm
Max Parallel Units per Busbar	10

Typical Applications

Urban and indoor-adjacent energy storage installations
Commercial buildings with strict fire safety requirements
Industrial facilities and data center backup storage
Utility and C&I storage projects with high safety standards

The cabinet is rated for operation from -20°C to 50°C with derating above 45°C, supports installation at altitudes up to 4000 m with derating above 2000 m, and is designed for outdoor deployment in C4 corrosion environments. Installation, maintenance and operation must be carried out by qualified technicians in strict compliance with safety regulations.

The cabinet is supplied under the Ohory brand. Contact our sales team for project-specific configuration, grid code compliance documents and a quotation.
